General Parameters
| Item | Specification |
|---|---|
| Operating Voltage | 12V–25V |
| Power | 84,000 |
| Weight | 975 grams |
| Memory Card Type | Micro SD Card (Single Card Slot) |
| Dimensions (L×W×H) | 166 × 115 × 184 mm |
| Real-Time Transmission Resolution | Thermal Imaging: 640*480; Visible Light: 720P, 1080P |
Environmental Parameters
| Item | Specification |
|---|---|
| Operating Temperature | -10°C ~ 45°C |
| Storage Temperature | -20°C ~ 70°C |
Gimbal Parameters
| Item | Specification |
|---|---|
| Angular Jitter | ±0.008° |
| Mounting Method | Detachable |
| Controllable Rotation Range | Tilt: +70° to -90°; Yaw: ±160° |
| Structural Design Range | Tilt: +75° to -100°; Yaw: ±175°; Roll: +90° to -50° |
| Maximum Control Speed | Tilt Angular Velocity: 120°/s; Yaw Angular Velocity: 180°/s |
| Intelligent Target Tracking | Supported |
| Item | Specification |
|---|---|
| Sensor | 1/2.8" CMOS; Total Pixels: 2.3 Megapixels |
| Lens | 30× Optical Zoom Lens, F:4.7–141 mm; Minimum Shooting Distance: 1 m (Wide) / 1.5 m (Tele); Horizontal Field of View: 60°–2.3° |
| Image Storage Format | JPEG |
| Video Storage Format | MP4 |
| Working Modes | Video Recording, Photography |
| Defogging | Electronic Defogging |
| Exposure Mode | Auto Exposure |
| Resolution | 1920*1080 |
| 2D Noise Reduction | Supported (Auto Activated) |
| 3D Noise Reduction | Supported (Auto Activated) |
| Electronic Shutter | 1/3 s ~ 1/30000 s |
| Exposure Control | Auto Mode |
| On-Screen Display (OSD) | Supported |
| Digital Zoom | Supported |
| Zoom Range | 1–30× Optical Zoom |
| One-Click Single Image Magnification | Supported |
| Item | Specification |
|---|---|
| Detector Type | Uncooled Infrared Microbolometer |
| Resolution | 704*576 |
| Thermal Sensitivity | ≤60 mK @ 300K |
| Frame Rate | 50 Hz |
Optical Performance
| Item | Specification |
|---|---|
| Lens | 25 mm Fixed Focus Lens |
| F-Number | F1 |
